608,83 € + IVA
Disponible para reserva
Connections
3″ in BSP, NPT and flanged inlet.
Applications
For road, rail tanker loading/unloading, filling of tanks
and containers, refuelling and loading/unloading
bunker boats (marine tankers) and small ships.
Also suitable for other applications where high loading rates are required and product contamination
and spillage needs to be minimized.
Media
Petroleum products: gasoline, diesel, oil etc.
Chemical products: ethylene oxide,
propylene oxide, acrylonitrile, butadiene, ammonia,
vinyl chloride, toluene, xylene, sulphuric acid,
phenol etc.
Gas: vapor recovery/balance systems
Dry powder.
Material of Body
Aluminium, brass/gunmetal, stainless steel,
Hastelloy and PEEK. Other materials on request.
Seals
Standard seals FPM (Viton®), EPDM, FFKM
(Chemraz®, Kalrez®), NBR. Other on request.
High Flow Rates / Low Pressure Drop
Allows maximum product transfer with minimal losses.
Recommended Maximum Flow Rates
2000 litres/minute (fuel)
Selectivity
– avoid mixing products
To avoid product contamination caused by connecting
a hose unit to the wrong tank unit, selective versions
of the hose and tank units are available.
Each unit has a number of selective positions, designated by a coded part number according to the coupling size – specify when placing order.
Interchangeability
Compatible with couplings of other manufacturers.
Hose Unit with Integrated Swivel
All hose units are supplied with an integrated swivel
